Huaʻōlelo huahana: DN50~700mm
Papa kaomi: PN0.6~ 4.0mpa
Pili waena: wai, mahu, aila, acid corrosive. etc
ʻO GYPYD363H ka hopena paʻakikī paʻakikī paʻa paʻa paʻa i hoʻopaʻa ʻia e kā mākou limahana loea ma hope o ka hoʻopili ʻana i ke ʻano a me nā hiʻohiʻona o nā huahana like ʻole a me ka lanakila ʻana i nā hemahema i ka hoʻohana ʻana i nā huahana kumu, ʻoi aku ka lōʻihi o kona ola lawelawe a ʻoi aku ka hilinaʻi. Hoʻohana ʻia ka valve butterfly i ke kumu hoʻolālā eccentric ʻekolu-dimensional, a ua haku ʻia ka hui hoʻopaʻa ʻana i ʻelua mau ʻāpana cone overlapping, Ma hope o ka waiwai eccentric o ke kino valve a me ka noho valve, hiki ke ʻike ʻia ke kikowaena o ka papa ʻaina butterfly i ka pili koke a me ka wehe ʻana o ka wehe a pani ʻana. Loaʻa ka labyrinth seal e ka laminated structure o ka butterly plate sealing ring metal a me ka graphite, ʻaʻole hiki ke hoʻohaʻahaʻa i ka torque hoʻololi o ka valve, akā e hōʻoiaʻiʻo nō hoʻi i ka hoʻokō ʻana o ka valve buterly. lele lele.
Nā ʻano kūkulu
1. Hoʻolālā paʻa, liʻiliʻi liʻiliʻi, kaumaha māmā, hana maʻalahi, maʻalahi e hoʻohana;
2. Hoʻohana ʻia ke ʻano he ʻekolu-dimensional eccentric multi-layer hard seaing structure, a hilinaʻi kāna hana holo moana a hiki i ka leakage zero;
3. ʻAʻohe flange o ka valve, e lawe mai i ka ʻoluʻolu a me ka nani i ka insulation a me ka ʻōwili ʻana o ka pipeline;
4. Loaʻa iā ia nā hiʻohiʻona o ka wela kiʻekiʻe, ke kiʻekiʻe kiʻekiʻe, ka pale ʻana i ka corrosion a me ke kūpaʻa ʻaʻahu
Hae hoʻokō
Hoʻolālā a me ka hana ʻana: GB / T12238, JB / T8527
Nui wili: GB/T12224
Ka lōʻihi o ka hale: GB/T122
Ho'āʻo a nānā: GB/T13927. JB/T9092
Palapala hana
Pāhana kūpono: Ke kila kalapona: -29'~425'c Ke kila kila: -40%~600
ʻO ka palapala hoʻouna: worm drive, pneumatic drive, uila uila, hydraulic drive
Aʻe: SQ61F laka welded poepoe kiwikā
Mua: DS343H pālua puʻupuʻu flange butterfly valve
He 228.80 miliona yuan ka nui o ka GCGV, e uhi ana i kahi o 22300m². Aia ma mua o 200 mau limahana, ʻoi aku ma mua o 30% i loaʻa ke kēkelē koleke a ʻoi aʻe paha, me 25 mau ʻenehana kiʻekiʻe a me waena. He mau kikowaena machining ka hui, CNC lathes, CNC vertical lathes,
